Trailing Cables
Owing to our vast experience in this field, we are able to manufacture and supply high quality Trailing Rubber Cables. Made using top quality annealed copper and elastomer compound, rubber cables are very durable and heat resistant. Our huge infrastructure facility is equipped with high-tech machines and technology. We manufacture these cables following modern techniques to obtain the right quality cables. The Trailing Cable is mainly used for trailing, festooning, mobile machines and Eot Cranes, Stacker Reclaimer, Winding & Rewinding Purpose, Hoists.
Core identification
- 1 core: Black
- 2 cores: Red & Black
- 3 cores: Red, yellow & Blue
- 4 cores: Red, Yellow, Blue & Green
- 5 cores: Red, Yellow, Blue, Black & Green
- 6 cores and above are numbered
Fillers
Natural or synthetic fibres or elastomer suitable
for the operating temperature and compatible with the insulating material.
Braiding
Min. 70 % Cotton Braiding Only With Double Sheath
Sheath
- General Service sheath Type SE1/SE2 of IS 6380-1984
- Heavy Duty Sheath Type SE3/SE4 of IS 6380-1984.
- CSP (Chlorosulphonated Polyethylene) more commonly as HOFR (Heat &
Oil Resistant & Flame Retardant)
Colour
Black
Voltage
1100 Volts
Standards
IS 9968(Pt-1)/1988 & BS6500
Applications
Reeling unreeling, Trailing, Festooning, Mobile
Machines, Cranes, Coal Handling, Conveyors Belts, Gantry Cranes, Double,
Over Head cranes, EOT Cranes, Container Handling Cranes.
Working Temperature of Commonly used Elastomeric Insulating and
Sheathing Materials
 |
|
Material |
Max. Cond. Temp. for continuous operation Deg C. |
Max. Cond. Temp. for short circuit Deg C. |
Min. Working Temp. Deg C. |
| Natural Rubber (VIR & TRS) |
60 |
200 |
-55 |
| Ethylene Propylene Rubber (EPR) |
90 |
250 |
-50 |
| Poly-chloro-prene (PCP) |
70 |
200 |
-40 |
| Chloro-sulpho-nated Poly-ethy-lene (CSP) |
90 |
200 |
-35 |
|
|
Note: Full Technical detail will be provided on
request through E-mail.
